E•NOTE•ION

A self-hosted, code-first content scheduler for Vestaboard split-flap displays. Define your board content as version-controlled JSON — cron schedules, templated messages, live data integrations, and a priority queue — with no web UI or cloud dependency required. Supports both the Note (3×15) and the Flagship (6×22).

This project is primarily agent-developed using Claude, with human design, decision-making, guidance, and review. See Philosophy for more on the approach.

Who this is for

E•NOTE•ION is built for developers and power users who want to treat their board like infrastructure: content in files, schedules in cron, secrets in env vars, deploys in Docker.

If you'd prefer a friendlier experience — a web UI, drag-and-drop scheduling, and a polished setup flow — check out FiestaBoard, which nails that use case beautifully.

See also

The Vestaboard community has built a lot of great tooling:

Project	What it does well
FiestaBoard	Full-featured self-hosted app with a web UI and a rich scheduling experience
Vestaboard+	Official cloud subscription with Zapier/IFTTT integration and a curated app marketplace
jparise/vesta	Clean Python library for the Vestaboard API — great if you want to build your own tooling
natekspencer/hacs-vestaboard	Home Assistant integration for triggering board updates from automations
Zapier / IFTTT	No-code workflow triggers via Vestaboard+ — lowest barrier to entry
MCP servers	Emerging tools for LLM-driven board updates from Claude and other agents

Running with Docker (recommended)

Pre-built multi-arch images (linux/amd64, linux/arm64) are published to the GitHub Container Registry on each release.

First copy config.example.toml to config.toml and fill in your API keys and settings (see Configuration below). Then run:

docker run -d \
  --name e-note-ion \
  --restart unless-stopped \
  -v /path/to/config.toml:/app/config.toml:ro \
  ghcr.io/jasonpuglisi/e-note-ion:latest

To mount personal content, add a volume pointing at /app/content/user:

  -v /path/to/your/content:/app/content/user \

Display model, public mode, and enabled contrib content are all configured in config.toml under [scheduler] — no environment variables needed for these settings. See Configuration for details.

Contrib integrations require their own API keys and configuration — see content/README.md for details.

Unraid

An Unraid Docker template is available in a separate repository. It exposes config file path, user content directory, timezone, and webhook port as UI fields.

Viewing container logs

Some integrations print important messages to stdout during startup or operation — for example, an authentication code and URL you need to visit to complete an OAuth flow. Check the container logs to see these messages.

Docker:

docker logs e-note-ion
# or follow live:
docker logs -f e-note-ion

Unraid: In the Unraid web UI, go to Docker → click the container icon next to e-note-ion → Logs.

Integrations that require interactive auth

Some integrations (e.g. Trakt.tv) use an OAuth device code flow: the scheduler prints a short code and URL to the container logs, you visit the URL on any device and approve access, and tokens are automatically saved to config.toml. No browser on the scheduler host is required.

For this to work, config.toml must be mounted read-write (not :ro) so the scheduler can persist the tokens:

# Correct — read-write (required when using auth-based integrations):
-v /path/to/config.toml:/app/config.toml

# Wrong — read-only prevents token persistence:
-v /path/to/config.toml:/app/config.toml:ro

Until auth is complete, templates from that integration are silently skipped and the display shows other content normally. See each integration's sidecar doc under content/contrib/ for setup details.

Configuration

Copy config.example.toml to config.toml and fill in your values:

cp config.example.toml config.toml
# edit config.toml — add your Vestaboard API key and any integration settings

config.toml is git-ignored and contains secrets — never commit it.

Key [scheduler] settings:

Key	Default	Description
model	"note"	Display model: "note" (3×15) or "flagship" (6×22)
public	false	When true, skip templates marked private = true (for shared/guest-visible spaces). Can be toggled at runtime via POST /webhook/scheduler with {"action": "public"} or {"action": "private"}
content_enabled	(absent)	Content filter for cron-scheduled templates in both user/ and contrib/: absent = all user loads, no contrib; ["*"] = all user + all contrib; ["bart", "my_quotes"] = only matching stems from either directory. Webhook-only integrations (plex, message, notion) are unaffected — their webhooks fire regardless of this setting.
timezone	system TZ	IANA timezone for cron job scheduling (e.g. "America/Los_Angeles")
min_hold	60	Minimum seconds any message stays on display before a high-priority (≥8) queued message can interrupt it. Set to 0 to disable (not recommended for physical displays).

Health monitoring

When the webhook listener is enabled, a health endpoint is available at GET /health. It returns a JSON summary of all registered integration statuses, useful for uptime monitoring (e.g. UptimeRobot).

Authentication: A credential is auto-generated on first startup — check the container logs for the plaintext secret. Pass it as X-Webhook-Secret: <secret> (preferred) or ?secret=<secret>.

HTTP status codes:

• 200 — everything healthy (or unknown)
• 503 — one or more targets degraded or errored

Response format:

{
  "status": "healthy",
  "uptime_seconds": 3600,
  "vestaboard": {
    "status": "healthy",
    "last_success": "2026-01-01T12:00:00+00:00",
    "last_expected_empty": null,
    "last_error": null,
    "last_error_message": null,
    "last_locked": "2026-01-01T07:00:00+00:00",
    "locked_events": 2,
    "success_rate": 1.0,
    "total_events": 10,
    "registered_at": "2026-01-01T08:00:00+00:00"
  },
  "integrations": {
    "weather": {
      "status": "healthy",
      "last_success": "2026-01-01T12:00:00+00:00",
      "last_expected_empty": null,
      "last_error": null,
      "last_error_message": null,
      "last_locked": null,
      "locked_events": 0,
      "success_rate": 1.0,
      "total_events": 10,
      "registered_at": "2026-01-01T08:00:00+00:00"
    }
  }
}

The vestaboard key tracks the display send path itself (POST to the Read/Write API) separately from integrations, so a Vestaboard outage does not smear across every integration's status — and vice versa. Each target tracks the last 20 events in a rolling buffer. Status levels: healthy (≥70% non-error rate), degraded (below threshold), error (all errors), unknown (no events yet). Expected empty data (e.g. nothing playing, no events today) counts as healthy — only API failures trigger degraded/error. Vestaboard locked responses (HTTP 423 during quiet hours) are tracked separately via last_locked / locked_events and do not affect status.

Health events are persisted to data/health.jsonl so that history survives container restarts. Events older than 7 days are automatically purged. In Docker, the data/ directory is an anonymous volume — no user configuration is needed for persistence across stop/start cycles.

A periodic health summary also logs to the console every hour, showing non-healthy integrations and their recent error rates.

Installing from PyPI

Requirements: Python 3.14+

pip install e-note-ion

Create a config file and run:

cp config.example.toml config.toml  # fill in your API key
e-note-ion                           # or: e-note-ion --config /path/to/config.toml

Use e-note-ion --help for CLI options.

Running from source

Requirements: Python 3.14+, uv

uv sync
cp config.example.toml config.toml  # fill in your API key
uv run e-note-ion

Display model, public mode, and content filter are set in config.toml under [scheduler]. See Configuration for details.

Content files

Content is defined as JSON files in two directories:

• content/contrib/ — bundled community-contributed content, disabled by default. Enable via [scheduler].content_enabled in config.toml.
• content/user/ — personal content. Loaded automatically when content_enabled is absent; filtered alongside contrib when it is set. Git-ignored; mount your own directory here or symlink to a private repo.

See content/README.md for the full content format reference, including template fields, variables, color squares, priority guidelines, schedule overrides, and available integrations.

Philosophy

Content as code. Board messages live in JSON files alongside your other dotfiles and configs. They're version-controlled, diff-able, and deployable the same way as everything else. There's no database to back up, no UI state to sync, and no vendor lock-in — just files, cron, and a single Python process.

An AI development experiment. E•NOTE•ION is also an ongoing exploration of agentic software development. Most of the implementation is written by Claude, with a human setting direction, reviewing plans, and making architectural calls. The goal isn't to remove the human — it's to see how far thoughtful human–AI collaboration can go on a real project with real constraints.

Development

uv sync
uv run pre-commit install

Run the full check suite before committing:

uv run ruff check .
uv run ruff format --check .
uv run pyright
uv run bandit -c pyproject.toml -r .
uv run pip-audit
uv run pre-commit run pretty-format-json --all-files
uv run pytest

All checks are also enforced as pre-commit hooks.

Integration tests

Integration tests hit the real APIs and are excluded from the default pytest run. To run them locally:

cp .env.example .env
# fill in your API keys — bare values, no surrounding quotes
uv run pytest -m integration -v

Required keys:

Key	Where to get it
VESTABOARD_VIRTUAL_API_KEY	web.vestaboard.com → Developer → Virtual Boards
CALENDAR_URL	Google/iCloud: secret-address .ics URL (see content/contrib/calendar.md)
CALENDAR_CALDAV_URL	https://caldav.icloud.com/ for iCloud CalDAV
CALENDAR_USERNAME	Apple ID email address
CALENDAR_PASSWORD	App-specific password from appleid.apple.com
BART_API_KEY	api.bart.gov/api/register.aspx
DISCOGS_TOKEN	discogs.com/settings/developers
TRAKT_CLIENT_ID	trakt.tv/oauth/applications → your app
TRAKT_CLIENT_SECRET	same app page
TRAKT_ACCESS_TOKEN	run Trakt auth flow once and copy from config.toml
TMDB_API_READ_ACCESS_TOKEN	themoviedb.org/settings/api (optional; enhances Plex/Trakt metadata)
CALENDAR_CARDDAV_URL	https://contacts.icloud.com/ for iCloud birthday integration
PARCEL_API_KEY	web.parcelapp.net → API key (requires Parcel Premium)
DIVING_NDBC_STATION	ndbc.noaa.gov station ID (e.g. 46221)
DIVING_LAT	Station latitude
DIVING_LON	Station longitude
YNAB_API_KEY	app.ynab.com/settings/developer → Personal Access Token
YNAB_BUDGET_ID	Budget UUID from the YNAB web app URL

.env is git-ignored — never commit it.
